Testing Procedure

With engine at normal operating temperature, tachometer installed, and parking and service brakes applied, make transmission stall test in "D", "2", "1" and "R" ranges at full throttle and note maximum RPM obtained. Engine speed should be within limits shown in STALL TEST SPEED  table. See also Figure .
