Section 1 (Continuously Variable Transaxle (CVT))
>>
Diagnostic Information and Procedures
>>
DTC P0961: Pressure Control Solenoid "A" Control Circuit Range / Performance
>>
Circuit Diagram
Circuit Diagram
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Transmission Fluid Pressure Sensor And Switch Circuit Diagram
Courtesy of SUZUKI OF AMERICA CORP.
