2WD Models

  1. Loosen nut of pivot pin.
  2. Place PNP switch and selector lever in "P" position.
  3. While pressing lower lever toward rear of vehicle (in "P" position direction), tighten nut to specified torque. Refer to "COMPONENTS (2WD MODELS) ".
    Fig 1: Identifying 2WD Models
    G03326060Courtesy of NISSAN MOTOR CO., U.S.A.
