Installation Procedure

Courtesy of GENERAL MOTORS COMPANY

Electronic Suspension Control Module (2) @ Electronic Suspension Control Module Bracket (3) - Install

CAUTION:

Electronic Suspension Control Module Bracket Nut (1) - Install and tighten [3x] - Fastener Specifications
Courtesy of GENERAL MOTORS COMPANY

Electronic Suspension Control Module Bracket (2) - Install
Electronic Suspension Control Module Bracket Bolt (1) - Tighten [2x] - Fastener Specifications
Connect the electrical connector.
Spare Tire - Install
Remove the support and lower the vehicle.
Perform the necessary programming and setup procedure:Control Module References
