Rear Inner Fender Replacement

WARNING: This page is about a different car, the 2008 Acura TL and 2007 Acura TL. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
  • Take care not to scratch the body.
  • Put on gloves to protect your hands.
  1. Remove the fuel pipe protector (see FUEL PIPE PROTECTOR REPLACEMENT  ).
  2. Remove the rear inner fender (A).
    1. Remove the screws (B) from the front and rear of the rear inner fender.
    2. Remove the bolts (C) and clips (D, E, F).
    3. Pull out the rear inner fender.
      NOTE: Driver's side shown, passenger's side is similar.
      Fig 1: Rear Inner Fender Fastener Locations With Torque Specification
      G05462336Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Install the inner fender in the reverse order of removal, and note these items:
    • Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.
    • Push the clips into place securely.
