Solenoid Park/Neutral Position (PNP) Switch

Fig 1: Identifying Shift-Lock
GLL140008Courtesy of VOLVO CARS CORPORATION
Component  Remarks  Resistance (Ω)
Solenoid Park/neutral position (PNP) switch Resistance between the solenoid terminals +20°C = 24.5-29.3 Ω
