Programming the outside temperature

Fig 1: Identifying Ignition ON

GLL101051

Courtesy of VOLVO CARS OF NORTH AMERICA.

Ignition on.
Read off the start value for the outside temperature. Make a note of the value. Program as necessary.

The programmable temperature is between 0° and +10°C in steps of 1°C.

NOTE: The outside temperature (start temperature) for additional heater can be reprogrammed. The start value can be set in the temperature interval 0°C to +10°C. This allows the start temperature to be adjusted to the customer wishes. If the customer experiences poor heating in the passenger compartment, the start temperature can be raised so that the heater starts at a higher outside temperature. It is recommended that the temperature is raised or lowered approximately 3°C for a noticeable difference. If the additional heater seems to start too often at too high an outside temperature, the start temperature can be lowered.

Fig 2: Identifying VCT2000 Diagnostic Tool Symbol In VIDA
Courtesy of VOLVO CARS OF NORTH AMERICA.

Fig 3: Programming Outside Temperature
Courtesy of VOLVO CARS OF NORTH AMERICA.
