Checking the parking brake cable: Notes

Check that the cables are not damaged or sticking.

Replace the cable if necessary according to Replacing the parking brake cable(s) .

Fig 1: Identifying Parking Brake Cable

Courtesy of VOLVO CARS OF NORTH AMERICA.

Were the brake cables OK? (Did not need to be remedied.)

• YES

  FAULT NOT FOUND:  Troubleshooting has been completed.

• NO

  Refer to Verification
