Signal missing. Permanent fault: Verification: Verification
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect the connectors, reinstall components etc.
- DSA control module connected.
- Start the engine.
Read off the load signal. Check that the value is OK.
HINT: Normal range idling with the engine at operating temperature, neutral selected and the air conditioning (A/C) off: approximately 36 μs. This value increases with load.
Is the value of the load signal OK?
- YES
VERIFIED: Troubleshooting has been completed.
- NO
Refer to Information
