Checking the charge lamp: Notes

• Ignition off.
• Ignition on.
• Start the engine.
• Rev the engine once.

  Check that charging lamp lights when the ignition is switched on and that the lamp goes out when the generator starts charging.

  Fig 2: Identifying Charging Lamp

  Courtesy of VOLVO CARS OF NORTH AMERICA.

Is the charge lamp OK?

• YES

  FAULT NOT FOUND:  Troubleshooting has been completed.

• NO

  Refer to Checking the (D+) supply from the generator (GEN)
