Transmission, Transporting

Special tools and workshop equipment required

• Engine/Gearbox Support Shackle (2 pc.): 10-222A/12
• Shop Crane: VAS6100

The : 10-222A/12  can be used when transporting the automatic transmission and for setting up the : 3282  .

-- To prevent the torque converter from falling out during transport, secure it a wire -A-, for example.

Fig 1: Converter Secured From Falling Out Using A Wire

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Mount the : 10-222A/12  at the top of the transmission housing.

-- Engage the hook of the : VAS6100  into the shackles a shown.

-- Lift the transmission using the : VAS6100  and : 10-222A/12  .
