Apply & Brake Clutch Application: Notes

NOTE: Before starting repairs to the transmission, first perform the On Board Diagnostic (OBD). See DIAGNOSIS - 01P article.

Fig 1: Locating Selector Elements Position

Courtesy of VOLKSWAGEN UNITED STATES, INC.
