DIGIMAT Control Module Identification - 50 State (GROUP 00, NO. 97-06)

Publication date: 1997-07-31
Reference number: GROUP 00, NO. 97-06
Supersedes refnos: GROUP 00, NO. 96-03

DIGIMAT CONTROL MODULE IDENTIFICATION - 50 STATE

TECHNICAL SERVICE BULLETIN

Reference Number(s): GROUP 00, NO. 96-03, GROUP 00, NO. 97-06, Date of Issue: July 31, 1997
Superceded Bulletin(s): GROUP 00, NO. 96-03, Date of Issue: December 20, 1996

DIGIMAT CONTROL MODULE (TCM), IDENTIFICATION

Model(s): 1993-97 Volkswagen Golf, Jetta 50-State

Group: 00 - General

Bulletin No.: 97-06

Date: July 31, 1997

NOTE: This bulletin supersedes Technical Bulletin Group 00, No. 96-03 dated December 20, 1996.

SERVICE INFORMATION

Use the charts shown in Fig 1 Fig 2 , and Fig 3 , to identify which Transmission Control Modules (TCM) are available for various 50-state ECM/TCM combinations.

NOTE: * This Bulletin should be used as a reference only. DO NOT update a vehicle unless a specific condition has been identified.

When replacing a TCM for any reason, the TCM must be paired with the Engine Control Module (ECM) according to the charts in Fig 1 Fig 2 , and Fig 3 .
Vehicle Identification Numbers (VIN) are for general reference only. Most VINs shown are approximate.
When multiple TCM Part Numbers are listed for a particular ECM/TCM combination, these are, shown in order of development i.e., the earliest TCM at the top with later TCMs following below.

CAUTION: Part numbers are for reference only. Always check with your Parts Dept. for the latest information.

Fig 1: Transmission/Engine Control Modules 93-95 Engine Code ABA

Fig 2: Transmission/Engine Control Modules 96-97 Engine Code ABA

Fig 3: Transmission/Engine Control Modules 95-97 Engine Code AAA
