Components [06/2016 - ]

Fig 1: Key Lock Unit Replacement Components (1 Of 2)
GTY724093Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Key Lock Unit Replacement Components With Torque Specifications (2 Of 2)
GTY704932Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
