Section 116 (Lin Communication System (Except Plug-In) (Diagnostic Codes))
>>
Lin Communication System
>>
DTC B2785: Communication Malfunction between ECUs Connected by LIN
>>
Wiring Diagram
DTC B2785: Communication Malfunction between ECUs Connected by LIN: Wiring Diagram
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Automatic Light Control System Wiring Diagram
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
