Emission Control System (1AR-FE) (Service Information): Canister: Components: Illustration

Fig 1: Identifying Canister Replacement Components With Torque Specifications (1 Of 2)
GTY195319Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002


Fig 1: Identifying Canister Replacement Components With Torque Specifications (2 Of 2)
GTY193942Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
