Ignition Key Cylinder Light: Components

WARNING: This page is about a different car, the 2007 Toyota RAV4. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Ignition Key Cylinder Light Components With torque Specifications
G04490882Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
