Door Control Receiver: Components

Fig 1: Door Control Receiver Replacement Components With Torque Specifications (1 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Door Control Receiver Replacement Components With Torque Specifications (2 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Door Control Receiver Replacement Components With Torque Specifications (3 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Door Control Receiver Replacement Components With Torque Specifications (4 Of 5)

Fig 5: Door Control Receiver Replacement Components With Torque Specifications (5 Of 5)
