Lower Instrument Panel: Disassembly

  1. REMOVE GLOVE COMPARTMENT DOOR STOPPER SUB-ASSEMBLY
    1. Disengage the claw and remove the glove compartment door stopper sub-assembly.
    Fig 1: Identifying Glove Compartment Door Stopper Sub-Assembly And Claw
    G06037888Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
