Front Seatback Heater: Installation

1. INSTALL FRONT SEATBACK HEATER ASSEMBLY
   1. Using a tacker, install the front seatback heater assembly to the end of the seatback cover with the 4 tack pins.
2. INSTALL SEPARATE TYPE FRONT SEATBACK COVER  (See REASSEMBLY )
   Fig 1: Identifying Front Seatback Heater Assembly And Tack Pins

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
3. INSTALL FRONT SEATBACK COVER WITH PAD  (See REASSEMBLY )
4. INSTALL FRONT SEAT CUSHION INNER SHIELD  (See REASSEMBLY )
5. INSTALL FRONT SEAT INNER BELT ASSEMBLY  (See INSTALLATION )
6. INSTALL FRONT SEAT CUSHION SHIELD  (See REASSEMBLY )
7. INSTALL VERTICAL ADJUSTING HANDLE  (See REASSEMBLY )
8. INSTALL VERTICAL SEAT ADJUSTER KNOB CAP  (See REASSEMBLY )
9. INSTALL RECLINING ADJUSTER RELEASE HANDLE  (See INSTALLATION )
10. INSTALL FRONT SEAT ASSEMBLY  (See INSTALLATION )
11. INSPECT FRONT SEAT SLIDE ADJUSTER LOCK  (See INSTALLATION )
12. INSTALL INNER SEAT TRACK COVER  (See INSTALLATION )
13. INSTALL OUTER SEAT TRACK COVER  (See INSTALLATION )
14. INSTALL FRONT SEAT HEADREST ASSEMBLY
15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL (w/ Front Seat Side Airbag)
16. INSPECT SRS WARNING LIGHT (w/ Front Seat Side Airbag)

HINT:

Inspect the SRS warning light (See DIAGNOSIS SYSTEM ).
