Fuel Sender Gauge Assembly (For Hatchback): Components

Fig 1: Identifying Fuel Sender Gauge Assembly (For Hatchback) Components Location (1 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Identifying Fuel Sender Gauge Assembly (For Hatchback) Components Location (2 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Identifying Fuel Sender Gauge Assembly (For Hatchback) Components Location (3 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Identifying Fuel Sender Gauge Assembly (For Hatchback) Components Location (4 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
