Inner Rear View Mirror: Removal

HINT:

EC mirror stands for "electrochromic mirror".

1. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (w/o EC Mirror)
   1. Push the cover in the direction indicated by the arrows labeled A and remove it.
   2. While holding down the claw in the direction indicated by the black arrow labeled B, slide the mirror in the direction indicated by the white arrow and remove it.
      Fig 1: Removing Inner Rear View Mirror Assembly (w/o EC Mirror)

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (w/ EC Mirror)
   1. Remove the inner rear view mirror cover.
   2. Remove the screw.
   3. Slide the mirror in the direction indicated by the arrow in the illustration and remove the mirror.
      Fig 2: Removing Inner Rear View Mirror Assembly (w/ EC Mirror)

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
