ECT and A/T Indicator for 2UZ-FE: Notes

Fig 1: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 1 Of 8)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 2 Of 8)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 3 Of 8)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 4 Of 8)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 5: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 5 Of 8)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 6: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 6 Of 8)

Fig 7: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 7 Of 8)

Fig 8: ECT And A/T Indicator System Wiring Diagram (2UZ-FE; 8 Of 8)
