Counter Shaft: Components

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Counter Shaft Components With Torque Specification (1 Of 2)
G05234424Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Exploded View Of Counter Shaft Components (2 Of 2)
G05234425Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
