Rear Cooler Control Panel: Components

WARNING: This page is about a different car, the 2006 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Rear Cooler Control Panel Components
G04440675Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
