Steering Pad Switch: Removal

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
REMOVE STEERING PAD ASSEMBLY (See REMOVAL )
REMOVE STEERING PAD SWITCH ASSEMBLY
1. Disconnect the connectors.
2. Remove the screw.
3. Detach the claw and remove the steering pad switch.

  Fig 1: Removing Steering Pad Switch
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
