Waveform 7
Throttle actuator negative terminal
WAVEFORM 7 REFERENCE
| ECM Terminal Name |
Between M- and ME01 |
| Tester Range |
5 V/DIV, 1 msec./DIV |
| Condition |
Idle after engine warmed-up |
HINT:
The duty ratio varies depending on the throttle opening operation.
