Front Shock Absorber: Disposal

FULLY EXTEND SHOCK ABSORBER ROD
DRILL HOLE TO DISCHARGE GAS FROM CYLINDER
Using a drill, make a hole in the cylinder, as shown, to discharge the gas inside.
CAUTION:
- When drilling, chips may fly out, so work carefully.
- The gas is colorless, odorless and non-poisonous.

  Fig 1: Using A Drill, Make A Hole In The Cylinder
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
