Front Shock Absorber: Disposal

  1. FULLY EXTEND SHOCK ABSORBER ROD
    Fig 1: Discharging Cylinder Gas Using A Drill
    G02631769Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  2. DRILL HOLE TO DISCHARGE GAS FROM CYLINDER

    Using a drill, make a hole in the cylinder as shown in the illustration to discharge the gas inside.

    CAUTION:
    • When drilling, chips may fly out, work carefully.
    • The gas is colorless, odorless and non-poisonous.
