Home >> Toyota >> 2004 >> Tundra Base, Automatic >> Repair and Diagnosis >> Electrical >> Body Electrical >> Accessory Power Socket >> Location

Accessory Power Socket: Location

Fig 1: Locating Power Outlet System Components (1 Of 2)
G02931773Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Locating Power Outlet System Components (2 Of 2)
G02931774Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
