Adjust Front Washer Nozzle

WARNING: This page is about a different car, the 2004 Toyota RAV4. However, it is still accessible from the selected car via links, so may be relevant.

Using a tool like the one shown in Fig 1, change the direction of the nozzle hole to adjust the point where washer fluid hits the windshield.

Fig 1: Adjusting Front Washer Nozzle
G02926640Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
