Fuel Pump ASSY: Components

Fig 1: Exploded View Of Fuel Injector Assembly Components (1 Of 2)
G02588905Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Exploded View Of Fuel Injector Assembly Components (2 Of 2)
G02588906Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
