Section 875 (Rear Axle)
>>
Unit Disassembly And Assembly
>>
Rear Drive Shaft
>>
Exploded View
Exploded View
WARNING:
This page is about a different car, the 2013 Nissan Armada. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Rear Drive Shaft With Torque Specifications
Courtesy of NISSAN NORTH AMERICA, INC.
