Air Conditioning: Receiver: Removal

Discharge Refrigerant From Refrigeration System
NOTE:
1. Evacuate air from refrigeration system.
2. Charge system with refrigerant and inspect for leakage of refrigerant.
  1. Specified amount: 650 +/- 50 g (22.92 +/- 1.76 oz.)
Remove Radiator Grille
Disconnect Two Liquid Tubes From Receiver
Remove the two bolts and disconnect the both tubes.

Fig 1: Removing Bolts From Radiator
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
1. Torque: 5.4 N.m (55 kgf.cm, 48 in..lbf)
NOTE:
1. Cap the open fittings immediately to keep moisture or dirt out of the system.
2. Lubricate 2 new O-rings with compressor oil and install them to the tubes.
Remove Receiver
1. Remove the holder bolt and pull receiver downward.
  NOTE:
  If receiver is replaced, add compressor oil to compressor.
  1. Add 20 cc (0.71 fl.oz.)
  2. Compressor oil: ND-OIL 8 or equivalent
2. Remove the bolt and holder.
