| Drive Axle Shaft Nut |
159 (216) |
| Drive Axle Shaft-To-Differential Carrier Bolts |
41 (56) |
| Rear Axle Hub & Bearing Assembly-To-Axle Carrier Bolts |
59 (80) |
| Rear Brake Caliper Mounting Bolts |
46 (62) |
| Rear Suspension Arm No. 1 & No. 2 Bolt (2WD) |
74 (100) |
| Rear Suspension Arm-To-Axle Carrier Bolt (4WD) |
131 (177) |
| Rear Suspension Arm-To-Rear Suspension Member Bolt (4WD) |
83 (113) |
| Shock Absorber Top (Center) Nut |
36 (49) |
| Shock Absorber-To-Body Top Nuts |
29 (39) |
| Shock Absorber-To-Knuckle Bottom Bolt |
188 (255) |
| Stabilizer Bar Link |
29 (39) |
| Strut Rod-To-Frame Bolt |
83 (113) |
| Strut Rod-To-Axle Carrier Bolt |
91 (123) |
| Suspension Member Front Side Nut |
85 (115) |
| Suspension Member Rear Side Nut |
134 (181) |
| Toe Adjust Cam Bolt (4WD) |
83 (113) |
| Wheel Lug Nuts |
76 (103) |
| INCH Lbs. (N.m) |
| Parking Brake Cable |
44 (5.0) |
