Riding Height Specifications
NOTE:
For 2WD Pickup, see Fig 1. For 4WD Pickup, see Fig 2. For all other models, see appropriate table. RIDING HEIGHT SPECIFICATIONS (TACOMA)
| Application |
Front In. (mm) |
Rear In. (mm) |
| 2WD |
2.20 (56) |
4.25 (108) |
| 4WD |
2.24 (57) |
Zero |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
