Steering Gear: Disassembly

  1. Attach steering gear to holding fixture. Mount assembly in vise. Remove solenoid valve (if equipped). Remove sector shaft adjuster screw lock nut and end cover retaining bolts. See Figure.
  2. Rotate sector shaft adjuster screw clockwise to remove until end cover. Tap sector shaft from housing. See Figure.
  3. Remove plunger guide nut, "O" ring, spring, plunger guide, and plunger. Remove worm gear valve bolts. Hold power piston while rotating worm shaft clockwise. Remove valve assembly and power piston.
    CAUTION: Ensure power piston does not come off worm shaft. DO NOT disassemble valve assembly or power piston.
  4. If removing needle bearings, remove oil seal, snap ring, spacer, and Teflon ring. See Figure. Press needle bearings from housing with Bearing Remover/Installer (09631-00070 ).
