Engine Controls - Tests W/Codes - EFI
>>
Ecu Terminal Identification
Ecu Terminal Identification
Fig 1: Tercel ECU Terminal Identification (Fuel Injected Models)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
