Door Lock Control Relay

Disconnect the connector from the relay. Inspect the connector on the wire harness side, between terminals as shown. See Fig 1-Fig 3 .
If circuit is as specified, inspect the door lock signal.

Fig 1: Identifying Door Lock Control Relay Wire Harness Terminals

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Testing Door Lock Control Relay Operation (1 Of 2)

Fig 3: Testing Door Lock Control Relay Operation (2 Of 2)
