Cruise Control Computer Circuit

Turn ignition OFF. Disconnect electrical connector from computer. Ensure terminals are clean and in good condition. Test circuits using CRUISE CONTROL COMPUTER CIRCUIT TEST SEQUENCE chart. See Fig 1.

Fig 1: Cruise Control Computer Circuit Test Sequence

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
