Choke Unloader

Fully open primary throttle valve, insert angle gauge and measure choke valve angle. Angle should measure 50 degrees. Bend primary throttle arm to adjust. See Fig 1.

Fig 1: Choke Unloader Adjustment

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
