Power Window & Back Door Warning Light Troubleshooting
POWER WINDOW & BACK DOOR WARNING LIGHT TROUBLE SHOOTING
| Problem | Possible Cause | Remedy |
|---|---|---|
| Power Window Does Not Work | Fusible Link Blow | Replace Fusible Link |
| " | Circuit Breaker Off | Reset breaker and check for short |
| " | ENGINE fuse blown | Replace fuse and check for short |
| " | Power window & wiper relay is faulty | Check relay |
| " | Power window regulator switch is faulty | Check switch |
| " | Back door control switch is faulty | Check switch |
| " | Cover top switch faulty | Check switch |
| " | Door lock detection switch is faulty | Check switch |
| " | Power window motor switch is faulty | Check motor |
| " | Rear wiper retraction defection switch faulty | Check switch |
| " | Wiring or ground faulty | Repair as needed |
| BACK DOOR Warning Light Does Not Light (Ignition Switch ON) | ENGINE Fuse Blown fault | Replace fuse and check for short |
| " | Light Bulb Burned out | Replace Bulb |
| " | Door Lock detection switch faulty (Back door Opened) | Check switch |
| " | Back door unlock warning switch faulty (Back door unlocked) | Check switch |
| " | Wiring or ground faulty | Repair as needed |
