Trouble Codes & Probable Cause For Codes
TROUBLE CODES & PROBABLE CAUSE FOR CODES
| Code No. |
Probable Cause |
| 2 & 3 |
Air Flow Meter or Circuit, ECU. |
| 4 |
Coolant Temp. Sensor or Circuit, ECU. |
| 5 |
Oxygen Sensor or Circuit, ECU. |
| 6 |
Ignition System Circuit, Distributor, Coil, Igniter, ECU. |
| 7 |
Throttle Position Sensor or Circuit, ECU. |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
