Camera - Forward Facing (Pitch Verification): Notes
WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2023 Tesla Model 3, 2022 Tesla Model 3, 2021 Tesla Model 3, 2020 Tesla Model 3, and 2019 Tesla Model 3. However, it is still accessible from the selected car via links, so may be relevant.
Last modified: 08/08/2023 15:57:03
NOTE:
See Personal Protection
to make sure to wear proper PPE when performing below procedure.
- 1053066-00-A Camera Calibration Target
- 1448868-00-A Wrench, 2.5 mm, Thin
NOTE:
This procedure describes how to verify forward facing camera pitch. It does not apply to the rear facing camera.
NOTE:
This procedure was designed for vehicles with factory suspension components. Check if the vehicle has modified suspension components, as this might affect whether calibration can be completed.
