Camera - Forward Facing Pitch Verification: Notes
Last modified: 08/08/2023 15:56:38
NOTE:
See Personal Protection
to make sure proper PPE is worn when performing the below procedure.
- 1448868-00-A Wrench, 2.5 mm, Thin
NOTE:
This procedure was designed for vehicles with factory suspension components. Check if the vehicle has modified suspension components, as this might affect whether calibration can be completed.
Revision History:
- 2023-08-07: Updated the procedure.
- 2023-07-18: Added steps to set the ride height and enable Jack Mode.
- 2023-06-19: Updated images and added notes to check measurements before each setup.
- 2023-06-08: Added specifications for HW4 and general image and step updates.
