Steering Yoke/Wheel - Remove And Replace: Notes
Last modified: 09/11/2023 10:09:47
NOTE:
See Personal Protection
to make sure to wear proper PPE when performing below procedure.
- 2023-11-08: Added a note to install the correct airbag variant.
- 2023-10-26: Added a warning.
- 2023-07-03: Updated tool.
- 2023-06-29: Updated firmware reinstall step; it is to be performed whenever the steering wheel/yoke is replaced.
WARNING:
If using this procedure to retrofit a steering wheel/yoke and change the configuration, DO NOT reinstall the old driver airbag, as it is incompatible. The driver airbag MUST be replaced with a new airbag that is compatible with the new steering wheel/yoke type. Confirm that the correct airbag is installed based on its part number. In addition, the airbag for a steering wheel has a label that identifies it as "ROUND - DRIVER". The airbag for a steering yoke does NOT have a similar label. Refer to the associated Service Document for explicit instructions on how to perform a steering wheel retrofit.
