Harnesses - Main Lower Dash and Front Trunk (RHD) (Dual Motor) - Remove And Replace: Notes

Last modified: 18/11/2022 10:16:11

Courtesy of TESLA, INC.

NOTE: Because the time to complete this procedure is approximately 12 hours, the procedure has been divided into 4 parts:

• Remove Main Lower Dash Harness
• Remove Front Trunk Harness
• Install Front Trunk Harness
• Install Main Lower Dash Harness

WARNING: This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.
