Transfer Oil Temperature Sensor Inspection

WARNING: This page is about a different variant/trim than selected.

Reference: TRANSFER OIL TEMPERATURE SENSOR REMOVAL AND INSTALLATION

Warm coupling air temperature sensor (1), as shown in figure, and make sure resistance value decreases as temperature rises.

Fig 1: Transfer Oil Temperature Sensor And Resistance Graph
G06528575Courtesy of SUZUKI OF AMERICA CORP.
