Home >> Suzuki >> 2012 >> Equator RMZ-4 >> Repair and Diagnosis >> Engine Mechanical >> Engine Mechanical - VQ40DE >> Repair Instructions >> Intake Manifold: Exploded View

Intake Manifold: Exploded View

Fig 1: Exploded View Of Intake Manifold Components With Torque Specification

G06440900

Courtesy of SUZUKI OF AMERICA CORP.
