Section 1 (Automatic Transmission System)
>>
Repair Instructions
>>
Oil Pump: Exploded View
>>
Oil Pump
Oil Pump
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Oil Pump
Courtesy of SUZUKI OF AMERICA CORP.
